12. System Cooling Performance Data
Ducted Split System
53QDMT12-718 Heat Pump
220-240V/1Ph/50Hz
Indoor Conditions Outdoor Ambient Temperature
ESP
in.wg
Fan
Speed
Air
Flow
cfm
Temp. °C 35°C 43°C 46°C 52°C
DB WB
Capacity
Btu/hr
Input
W
Capacity
Btu/hr
Input
W
Capacity
Btu/hr
Input
W
Capacity
Btu/hr
Input
W
Total Sensible Total Sensible Total Sensible Total Sensible
0
in.wg
High
400
21 15
12105 9980 1195 11580 10025 1230 11300 9920 1245 10735 9710 1275
24 17 12475 10445 1240 11705 10150 1305 11460 10060 1330 10975 9870 1380
27 19
13000 10480 1265 12105 10230 1330 11700 10025 1355 10885 9610 1400
32 23
13530 12290 1325 12475 12000 1380 12110 11875 1395 11385 11630 1420
Medium
345
21 15
11500 9185 1150 11005 9225 1185 10735 9130 1200 10200 8935 1225
24 17
11855 9615 1195 11120 9340 1255 10890 9260 1280 10430 9085 1325
27 19
12350 9645 1215 11500 9415 1280 11115 9225 1305 10345 8845 1345
32 23
12855 11310 1275 11855 11040 1325 11505 10925 1340 10820 10700 1365
Low
250
21 15
10580 7810 1070 10125 7840 1100 9880 7765 1115 9385 7595 1140
24 17
10905 8170 1110 10235 7945 1170 10020 7870 1190 9595 7720 1235
27 19
11365 8200 1130 10580 8000 1190 10230 7840 1210 9515 7520 1250
21 23
11830 9610 1185 10905 9390 1235 10585 9290 1250 9955 9095 1270
0.08
in.wg
High
344
21 15
11860 9605 1180 11345 9820 1215 11070 9725 1230 10520 9520 1260
24 17
12225 10045 1225 11470 9950 1290 11235 9860 1315 10755 9670 1365
27 19
12740 10070 1250 11860 10030 1315 11465 9820 1340 10670 9415 1390
32 23
13250 11850 1310 12220 11750 1365 11860 11635 1380 11150 11395 1405
Medium
289
21 15
11270 8840 1135 10780 9040 1170 10520 8950 1185 9995 8760 1210
24 17
11615 9245 1180 10900 9155 1240 10675 9075 1265 10220 8905 1315
27 19
12105 9265 1200 11270 9230 1265 10895 9040 1290 10140 8665 1335
32 23
12590 10905 1260 11610 10815 1315 11270 10705 1325 10595 10490 1350
Low
203
21 15
10370 7515 1055 9920 7685 1085 9680 7610 1100 9195 7450 1125
24 17
10685 7855 1095 10025 7785 1155 9820 7710 1175 9400 7565 1220
27 19
11135 7875 1120 10370 7845 1175 10025 7685 1200 9330 7365 1245
21 23
11585 9270 1170 10685 9190 1220 10370 9100 1235 9750 8915 1255
0.12
in.wg
High
312
21 15
11740 9415 1170 11235 9730 1205 10960 9625 1220 10420 9425 1250
24 17
12100 9845 1215 11360 9860 1280 11125 9770 1305 10660 9590 1355
27 19
12610 9865 1240 11740 9930 1305 11350 9730 1330 10575 9325 1380
32 23
13105 11635 1300 12085 11625 1355 11730 11505 1370 11025 11270 1400
Medium
257
21 15
11155 8665 1125 10675 8955 1160 10415 8855 1175 9900 8670 1200
24 17
11495 9060 1170 10795 9075 1230 10570 8990 1255 10130 8825 1305
27 19
11980 9080 1195 11155 9140 1255 10785 8955 1280 10050 8585 1325
32 23
12450 10705 1250 11485 10695 1305 11145 10585 1320 10475 10375 1345
Low
180
21 15
10265 7365 1045 9820 7615 1080 9580 7530 1090 9110 7370 1120
24 17
10580 7700 1085 9930 7710 1145 9725 7645 1170 9320 7500 1210
27 19
11025 7715 1110 10265 7770 1170 9920 7615 1190 9245 7300 1235
21 23
11455 9100 1165 10565 9095 1210 10255 9000 1225 9640 8815 1250
0.16
in.wg
High
275
21 15
11620 9225 1160 11115 9620 1195 10845 9525 1210 10300 9320 1240
24 17 11970 9635 1205 11235 9745 1270 11000 9655 1295 10535 9475 1345
27 19 12475 9650 1230 11620 9820 1295 11230 9620 1320 10450 9220 1370
32 23 12965 11415 1290 11960 11505 1345 11610 11390 1360 10920 11155 1390
Medium
220
21 15
11040 8490 1115 10560 8850 1150 10305 8765 1165 9785 8580 1195
24 17 11375 8865 1160 10675 8965 1220 10450 8890 1245 10010 8725 1295
27 19 11855 8885 1185 11040 9040 1245 10670 8850 1270 9930 8485 1320
32 23 12320 10510 1240 11365 10585 1295 11030 10480 1310 10375 10265 1335
Low
156
21 15
10160 7215 1040 9715 7525 1070 9480 7450 1085 9005 7295 1110
24 17 10465 7535 1080 9820 7625 1135 9615 7555 1160 9210 7410 1205
27 19 10905 7550 1100 10160 7685 1160 9820 7525 1180 9135 7210 1225
21 23 11335 8930 1155 10455 9000 1205 10150 8910 1215 9545 8725 1245
42QDMT12-718
38QDMT12-718
