10. PART LIST OF OUTDOOR UNIT
QTY./UNIT
38QH-H 38QH-C
SR. DESCRIPTION
PART
NUMBER
30 36 30 36
1 COMPRESSOR COMPLETE WITH GROMMETS & SPACERS
1.1 Copeland Comp. CR37KQ-PFT 01500256 1 1
1.2 Copeland Comp. CR47KQ-PFZ 01500172 1 1
2 COND. BASE 08107402 1 1 1 1
3 SUPPORTING LEG ASSY 36314043 4 4 4 4
4 COND. PARTITION 06307407 1 1
06307436 1 1
5 CONDENSER COIL SUBASSY.
5.1 Cond. Coil 2 Row – 33.15” x 22” - 14FPI 02600234 1 1
5.2 Cond. Coil 2 Row – 33.15” x 28” - 15FPI 02600231 1 1
6 CONDENSER MOTOR SUPPORT SUBASSY. 36313880 1 1 1 1
7 CONDENSER MOTOR
7.1 Motor 1/10 HP-880 RPM 02400154 1 1
7.2 Motor 1/5 HP-860 RPM 02400179 1 1
8 PROPELLER C/W SOCKET SET SCREW 8 X 8 MM 02600441 1 1 1 1
9 ORIFICE PROPELLER 02803112 1 1 1 1
10 COND. SHROUD 08107406 1 1
06307435 1 1
21 CARRIER LOGO 02900615 1 1 1 1
12 HANDLE 02803110 1 1 1 1
13 GUARD PROPELLER 02803113 1 1 1 1
14 COND. BACK PANEL 06307409 1 1
06307434 1 1
15 COUPLING PANEL 06307410 1 1 1 1
16 SERVICE DOOR 02803106 1 1 1 1
17 COIL GUARD 02803114 1 1
02803115 1 1
18 COND. COVER 08107400 1 1 1 1
19 ELECTRICAL BOX SUBASSY 36314125 1
36314097 1
36314223 1
36314222 1
19.1 DUAL CAPACITOR
19.1.1 Dual Capacitor 50 + 5 MFD/440 VAC 02400379 1 1
19.1.2 Dual Capacitor 60 + 5 MFD/440 VAC 02400377 1 1
19.2 CONTACTOR FOR COMPRESSOR
19.2.1 Contactor 2 poles – 25 Amps 02400580 1 1
19.2.2 Contactor 2 poles – 30 Amps 02400572 1 1
19.3 TERMINAL BLOCKS
19.3.1 Terminal Block 6 Poles-30 Amps 02501433 1 1
19.3.2 Terminal Block 4 Poles-30 Amps 02501405 1 1
19.3.3 Terminal Block 3 Poles-30 Amps 02501315 1 1 1 1
19.4 COND. ELECTRICAL BOX 06307405 1 1 1 1
19.5 CAPACITOR CLAMP 02804078 1 1 1 1
19.6 SUPPORT CABLE 02802523 1 1 1 1
19.7 WIRE HARNESS SET 02500879 1 1
02500872 1 1
19.8 PTC STARTER FOR COMPRESSOR
19.8.1 PTC Starter Model SPP POW-R-PAK 02501579 1 1
19.8.2 PTC Starter Model SPP5 02501578 1 1
19.9 LOW PRESSURE CONTROL 02400638 1 1 1 1
19.10 PILOT LIGHT FOR LOW PRESSURE CONTROL 02502315 1 1 1 1
20 REVERSING VALVE & ELECTRIC COIL
02200404 1
02200406 1
21 ACCUMULATOR 02301012 1
02301013 1
22 SENSOR – OUTDOOR COIL 02503015 1 1
23 TUBING 36314124 1
36314096 1
36313934 1
36314193 1
