8. PART LIST OF INDOOR UNIT
QUANTITY / UNIT
42QH- H 42QH- C
NO. PART NAME
PART
NUMBER
30 36 30 36
1 Mounting Bracket 02802426 1 1 1 1
2 Base Pan 02802427 1 1 1 1
3 End Plate Support – L 02802425 1 1 1 1
4 Blower L 02802434 1 1 1 1
5 Blower R 02802435 1 1 1 1
6 Bracket Motor 02802422 3 3 3 3
7 Center Bearing W/Bracket 02802423 1 1 1 1
8 Motor 02400017 1 1 1 1
9 Evap. Support-R 02802433 1 1 1 1
10 Evap. Support-L 02802432 1 1 1 1
11 Drain Hose Connector 02802399 1 1 1 1
12 Drain Hose 02802398 1 1 1 1
13 Horizontal Louver 02802424 1 1 1 1
14 Drain Pan 02802428 1 1 1 1
15 Step Motor MP35 02400015 1 1 1 1
16 Deflector 02802430 16 16 16 16
17 Bar Gang 02802431 4 4 4 4
18 Deflector with Arm 02802429 4 4 4 4
19 Evap. Coil-3R x 5C x 3/8” 02600159 1 1 1 1
20 Frame Grille 02802436 1 1 1 1
21 Screw Cover 02802400 4 4 4 4
22 Air Filter 02802401 2 2 2 2
23 Decorative Panel 02802437 1 1 1 1
24 Control Box Assy
Main PCB Cool/Heat 02503154 1 1
24.1
Main PCB Cool Only 02503186 1 1
24.2 Return Air Sensor 02503149 1 1 1 1
24.3 Indoor Coil Sensor 02503150 1 1 1 1
24.4 Capacitor 2.5 MF/ 450VAC 02400016 1 1 1 1
24.5 Lamp PCB/IR Receiver 02503151 1 1 1 1
24.6 Control Box 02503156 1 1 1 1
24.7 Auxiliary Switch 02503163 1 1 1 1
24.8 Wire Harness – Auxiliary Switch 02503162 1 1 1 1
24.9 Wire Harness – Lamp PCB 02503164 1 1 1 1
24.10 Extension Wire 8M 02503153 1 1
Remote Control Cool / Heat 02503155 1 1
25
Remote Control Cool Only 02503178 1 1
26 Battery size AAA-15.V 02501125 2 2 2 2
