11.4 - Fans
Each fan motor assembly is equipped with a high-performance impeller made from recyclable composite material.
The motors are three-phase, with lifetime lubricated bearings and class F insulation (IP55 level).
When option 12 is not selected, the pressure available at the fan outlet is zero.
According to regulation No. 327/2011 implementing directive 2009/125/EC with regard to eco-design requirements for fans
driven by motors with an electric input power between 125 W and 500 kW.
Product 30RB Standard
(1)
30RB Standard
(2)
30RB option 6B, 12,
15LS, 16, 28
Option 17
Overall e󰀩ciency % 37,1 38,6 40,2 47,3
Measurement category A A A A
E󰀩ciency category Static Static Static Static
Target e󰀩ciency level ERP2015 N(2015) 40 N(2015) 40 N(2015) 40 N(2015) 40
E󰀩ciency level at the optimum e󰀩ciency
point
43,8 42,9 43,4 52,2
Speed regulator No No Yes Yes
Year of manufacture See label on the unit See label on the unit See label on the unit See label on the unit
Fan manufacturer Simonin Simonin Simonin Simonin
Motor manufacturer Leroy Somer Leroy Somer Leroy Somer EBM
Fan PN 00PSG000000100 00PSG000000100 00PSG000000100 00PSG000000100
Motor PN 00PPG000464500 00PPG000464600 00PPG000464700 00PPG000464800
Nominal motor capacity kW 0,88 2,09 2,41 1,68
Flow rate m
3
/s 3,59 4,07 5,11 4,24
Pressure at optimum energy e󰀩ciency Pa 90 195 248 174,6
Nominal Speed rpm 710 966 1137 959
Specic ratio 1,002 1,002 1,002 1,002
Relevant information to facilitate the
disassembly, recycling or removal of the
product at the end of life
See the Maintenance
manual
See the Maintenance
manual
See the Maintenance
manual
See the Maintenance
manual
Relevant information to minimise impact on
the environment
See the Maintenance
manual
See the Maintenance
manual
See the Maintenance
manual
See the Maintenance
manual
According to regulation No. 640/2009 and amendment 4/2014 implementing directive 2009/125/EC with regard to ecodesign
requirements for electric motors.
Product 30RB Standard
(1)
30RB Standard
(2)
30RB option 6B, 12,
15LS, 16, 28
Option 17
Motor type
Two-speed
asynchronous
Two-speed
asynchronous
Asynchronous Synchronous
Number of poles 8 6 6 -
Rated input frequency Hz 50 50 60 50
Nominal voltage V 400 400 400 400
Number of phases 3 3 3 3
Motor included in the application
domain of the regulation 640/2009
and amendment 4/2014
No No No NO
Justication for exemption Article 2.1 Article 2.1 Article 1.2.c).(ii) Article 2.1
Ambient air temperature for which
the motor is specically designed
°C 70 70 70 70
(1) For sizes 30RB 040R - 055R only
(2) For sizes 30RB 060R - 160R only
The data above for the fans and motors are compulsory as part of the ecodesign regulations, and are provided for a self-contained
component (not included in the cooling system).
9 - NOMINAL SYSTEM WATER FLOW RATE CONTROL
35
