Table 10 — Configuration Mode and Sub-Mode Directory
SUB-MODE
KEYPAD
ENTRY
ITEM DISPLAY
ITEM
EXPANSION
COMMENT
UNIT UNIT CONFIGURATION
SIZE XX UNIT SIZE
SZA.1 XX COMPRESSOR A1 SIZE Unit Dependent
SZA.2 XX COMPRESSOR A2 SIZE Unit Dependent
SZA.3 XX COMPRESSOR A3 SIZE Unit Dependent
SZA.4 XX COMPRESSOR A4 SIZE Unit Dependent
SZB.1 XX COMPRESSOR B1 SIZE Unit Dependent
SZB.2 XX COMPRESSOR B2 SIZE Unit Dependent
SZB.3 XX COMPRESSOR B3 SIZE Unit Dependent
SZB.4 XX COMPRESSOR B4 SIZE Unit Dependent
SH.SP XX.X F SUPERHEAT SETPOINT Default: 9 F
FAN.S NUMBER OF FANS 1 = One Fan
2 = Two Fans
3 = Three Fans
4 = Four Fans
EXV YES/NO EXV MODULE INSTALLED?
Default: Yes
A1.TY YES/NO COMPRESSOR A1 DIGITAL?
Default: No
Yes = A1 Compressor is Digital
Scroll
MAX.T 0 to 12 MAXIMUM A1 UNLOAD TIME
Default: 7
Max 12 010,015
Max 10 018-060
OPT1 UNIT OPTIONS 1 HARDWARE
FLUD X COOLER FLUID
Default: Water
1 = Water
2 = Medium Temperature
Brine
MLV.S YES/NO MINIMUM LOAD VALVE SELECT Default: No
D.G.EN ENBL/DSBL DISCHARGE GAS TEMP ENABLE
CSB.E ENBL/DSBL CSB BOARDS ENABLE
CPC ON/OFF COOLER PUMP CONTROL Default: Off
PM1E YES/NO COOLER PUMP 1 ENABLE
PM2E YES/NO COOLER PUMP 2 ENABLE
PM.P.S YES/NO COOLER PMP PERIODIC STRT Default: No
PM.SL X COOLER PUMP SELECT Default: Automatic
0 = Automatic
1 = Pump 1 Starts first
2 = Pump 2 Starts first
PM.DY XX MIN COOLER PUMP SHUTDOWN DLY
0 to 10 minutes, Default: 1
min.
PM.DT XXXX HRS PUMP CHANGEOVER HOURS Default: 500 hours
ROT.P YES/NO ROTATE COOLER PUMPS NOW User Entry
EMM YES/NO EMM MODULE INSTALLED
CND.T 0,1 COND HX
0 = RTPF
1 = MCHX Default MCHX
MOPS XX EXV MOP SET POINT Range: 40 - 80 Default: 50
APPR XX CONFIG APPROACH SETPOINT Range: 5 - 40 Default: 9.0
ENTER
ENTER
