NON-PROGRAMMABLE THERMOSTAT CONFIGURATION RECORD
Date
Owner/Operator
A) Hardware Configuration
R19 Resistor located on Model HP and 2S only. (Uncut = Enable Heat Pump Operation,
Cut = Air Conditioner Operation)
No R19 Resistor present. (Model AC thermostat only)
Thermostat Model No.
B) Mode Settings
C) Configuration Options
Mode (Off, Heat, Cool, Auto, Eheat)
Heating Set Point Value
Cooling Set Point Value
Fan (Auto or On)
1 Anticipator (1-9: factory default = 3)
2 Clean Filter Timer (Off or 1-9: factory default = 2)
3 Fahrenheit or Celsius (F or C: factory default = F)
4 Fan On with W (Off or On: factory default = Off)
5-6 N/A
7 Zoning Selection (Off or On: factory default = Off)
8 Auxiliary Heat Lockout (Off or 5-55 F: factory default = Off)
9-12 N/A
13 Room Temperature Offset (-5 to +5: factory default = 0)
14 N/A
15 Enable Auto Mode (Off or On: factory default = On)
