Casio CTK-691 Midi Implementation

62
Note 1:
The relationship between the "Bank", "Number" and "ps (parameter set)" are as shown below.
36 User Drawbar Parameter Set
System Exclusive Format
Bank Number ps Bank Number ps
1 1 0020H 5 1 0030H
1 2 0021H 5 2 0031H
1 3 0022H 5 3 0032H
1 4 0023H 5 4 0033H
2 1 0024H 6 1 0034H
2 2 0025H 6 2 0035H
2 3 0026H 6 3 0036H
2 4 0027H 6 4 0037H
3 1 0028H 7 1 0038H
3 2 0029H 7 2 0039H
3 3 002AH 7 3 003AH
3 4 002BH 7 4 003BH
4 1 002CH 8 1 003CH
4 2 002DH 8 2 003DH
4 3 002EH 8 3 003EH
4 4 002FH 8 4 003FH
Field Value
01 SYSEX F0
02 MAN 44
03 MOD 11,02
04 dev Either 00 to 1F, or 7F
05 act 04(HDS), 05(HDR), 07(Control)
06 cat Drawbar = 0D
07 prm 00
08 ilen/dlen See "IV This Model's System Exclusive Messages".
09 ps Indicates the drawbar number being transferred.
For details, see "38 About Parameter Set (PS) numbers".
10 index See "IV This Model's System Exclusive Messages".
11 data See "IV This Model's System Exclusive Messages".
12 sum See "IV This Model's System Exclusive Messages".
13 EOX F7
