63
37 SMF Parameter Set
System Exclusive Format
Data Format
Bulk dumping SMF data transfers the data with a 128-byte header appended as shown below. The header data starts with
an 8-byte file name, which is displayed by this Model after receipt.
38 About Parameter Set (PS) numbers
When using a System Exclusive message to transfer a user parameter set or user parameter set parameters, the
specified parameter set number do not necessarily need to start from zero when the parameter set numbers are
located after the preset parameter set.
Refer to the table below for user area parameter set number for each category.
Field Value
01 SYSEX F0
02 MAN 44
03 MOD 11,02
04 dev Either 00 to 1F, or 7F
05 act 04(HDS), 05(HDR), 07(Control)
06 cat SMF = 10
07 prm 00-7F
08 ilen/dlen See "IV This Model's System Exclusive Messages".
09 ps Indicates the SMF number being transferred.
For details, see "38 About Parameter Set (PS) numbers".
10 index See "IV This Model's System Exclusive Messages".
11 data See "IV This Model's System Exclusive Messages".
12 sum See "IV This Model's System Exclusive Messages".
13 EOX F7
Header 128Bytes Name 8Bytes
Reserved 120Bytes
SMF Data
PS Category User PS Header (Decimal) Number of User PS (Decimal)
Tone (with wave) 750 (850) 120 (20)
Timbre 520 20
Drum 16 4
Voice 950 80
Instrument 240 512
Wave 800 1792
Rhythm 140 16
Song 0 5
SMF 0 200
DrawbarOrgan 100 100
Registration 32 (See "35 Registration Data".) 32
