Casio DT-X200-10E Hardware Manual

DT-X200 Hardware Manual P.31
CAS
IO COMPUTER CO., LTD.
4.2. Electrical Performances
4.2.1. Ethernet Cradle
Item Specification Remark/Condition
Input voltage DC12V±5%
4.2.2. USB Cradle／USB and Charging Unit
Item Specification Remark/Condition
Input voltage DC5V±5%
4.2.3. Dual Battery Charger
Item Specification Remark/Condition
Input voltage 12V±5%
Approx. 0.03A Without battery
Consumption Current
Approx. 1.17A(not connected) At charging with battery
Charging time One battery mounted:
Approx. 4.5hours
Two batteries mounted:
Approx. 5hours
Room temperature
No. of connection Max 3 chargers
4.2.4. Cradle-type Dual Battery Charger
Item Specification Remark/Condition
Input voltage DC19V±1V
Consumption Current Approx. 1.6A (Not Multiple connection)
Number of connection Max 3 chargers
4.2.5. AC Adaptor
Item AD-S15050B AD-S42120C AD-S90190C
Input voltage AC100V/240V AC100V/240V
AC100V/240V
Output voltage DC5V DC12V
DC19V
Output Current
0～3000mA 0～3500mA
0～4740mA
Input voltage Frequency
47Hz～63Hz 47Hz～63Hz
47Hz～63Hz
Output voltage Range
4.75V～5.25V 11.4V～12.6V
15.2V～16.8V
4.2.6. Battery pack
Item HA-K23XLBAT Remark/Condition
Rated Capacity 2860mAh
Rated Voltage 3.7V
