Casio Exilim EX-S5 User Manual

17
Quick Start Basics
1. Open the battery cover.
Pressing the battery cover, slide it in the direction
indicated by the arrow.
2. Load the battery.
With the EXILIM logo on the
battery facing upwards (in the
direction of the monitor
screen), hold the stopper next
to the battery in the direction
indicated by the arrow as you
slide the battery into the
camera. Press the battery in
until the stopper secures it in
place.
3. Close the battery cover.
Pressing the battery cover against the camera, slide
it closed.
• For information about how to replace the battery,
see page 128.
To load the battery
2
1
Stopper
EXILIM logo
Front
Back
Battery contacts
1
2

Casio Exilim EX-S5 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.3 \
Maximum image resolution	3648 x 2736 pixels
Digital zoom	4 x
Optical zoom	3 x
Combined zoom	12 x
Focal length range	6.3 - 18.9 mm
Interface	USB, AV
Digital SLR	No
Camera shutter speed	1/2 - 1/2000 s
Focal length (35mm film equivalent)	35.5 - 106.5 mm
Light metering	Centre-weighted, Spot
ISO sensitivity	64, 100, 200, 400, 800, 1600
Light exposure modes	Auto
Internal memory	3 MB
Compatible memory cards	sd, sdhc
Motion JPEG frame rate	30 fps
Video formats supported	Avi, M-JPEG
Maximum video resolution	848 x 480 pixels
Audio system	Mono
Display diagonal	2.7 \
Display resolution (numeric)	479 pixels
USB version	2.0
White balance	auto, Cloudy, daylight, manual, Shade, Tungsten
Camera playback	Single image
Self-timer delay	2, 2+10, 10 s
Product color	Silver
Battery type	NP-80
Number of batteries supported	1
Cables included	AV, USB
Auto focusing (AF) modes	monitoring auto focus, multi point auto focus, spot auto focus
Flash modes	auto, fill-in, Flash off, Red-eye reduction
Camera shutter type	electronic, mechanical

Weight and Dimensions

Depth	56.5 mm
Width	96.8 mm
Height	17.8 mm
Weight	100 g
