Casio Exilim EX-Z29 User Manual

43
Snapshot Tutorial
The easy mode eliminates troublesome setups and simplifies snapshot recording.
This mode is recommended for those who are new to digital imaging.
1. In the REC mode, press [SET].
2. Use [8] and [2] to select the second Control Panel option from the
bottom (easy Mode).
3. Use [4] and [6] to select “
|
On” and then press [SET].
This enters the easy mode.
4. Focus the image.
While the focus frame is aligned with the subject, half-press the shutter button.
5. Shoot the image.
When the image is focused, press the shutter button the rest of the way.
This records the snapshot.
. Using the easy Menu
The easy menu contains flash, self-timer, and image size settings, plus an item for
exiting the easy mode.
While the camera is in the easy mode, all the other settings (besides Flash, Self-
timer, Image Size, and easy Mode) on the REC tab menu (page 133) and Quality tab
menu (page 133) are fixed at preset optimum values. Any settings you configured on
these tabs are not used in the easy mode.
IMPORTANT!
• To use the Set Up tab menu (page 134), you need to exit the easy mode. To do
this, select the “easy Mode” item in step 2 of the following procedure, and then
select
l
in step 3. After that, you can use the Set up tab menu as you normally
do.
Using the easy Mode

Casio Exilim EX-Z29 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.5 \
Maximum image resolution	3648 x 2736 pixels
Digital zoom	4 x
Optical zoom	3 x
Combined zoom	12 x
Focal length range	6.2 - 18.6 mm
Lens structure (elements/groups)	6/5
Interface	USB 2.0
Digital SLR	No
Camera shutter speed	1/2 - 1/2000 s
Focal length (35mm film equivalent)	37.5 - 112.5 mm
Auto focusing (AF) modes	continuous auto focus, multi point auto focus, spot auto focus
Manual focusing range (wide)	∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	100
Light exposure modes	Auto
Motion JPEG frame rate	30 fps
Video formats supported	Avi, M-JPEG
Maximum video resolution	848 x 480 pixels
Audio system	Mono
Display diagonal	2.7 \
Display resolution (numeric)	479 pixels
I/O ports	A/V
USB version	2.0
White balance	auto, Cloudy, daylight, Fluorescent, manual, Tungsten
Camera playback	movie, single image, slide show
Self-timer delay	2 s
Playback zoom (max)	8 x
Product color	Black
Battery type	NP-60
Number of batteries supported	1
Flash modes	auto, Flash off, Red-eye reduction
Flash range (tele)	0.4 - 1.5 m
Flash range (wide)	0.15 - 2.8 m
Flash recharging time	6 s
Internal memory	17.8 MB
Compatible memory cards	sd
Camera shutter type	electronic, mechanical

Weight and Dimensions

Width	0 mm
Weight	125 g
