Casio Exilim EX-Z29 User Manual

82
Printing
You can connect the camera directly to a printer that supports PictBridge and print
images without going through a computer.
. To set up the camera before connecting to a printer
1. Turn on the camera and press [MENU].
2. On the “Set Up” tab, select “USB” and then press [6].
3. Use [8] and [2] to select “PTP (PictBridge)”, and then press [SET].
. Connecting the Camera to a Printer
Use the USB cable that
comes bundled with the
camera to connect the
camera to your printer’s
USB port.
• The camera does not
draw power over the USB
cable. Make sure the
camera’s battery is
sufficiently charged
before connecting.
• Make sure that you insert
the cable connector into
the USB/AV port until you
feel it click securely into
place. Failure to insert the
connector fully can result
in poor communication or
malfunction.
• Note that even while the connector is fully inserted, you
still will be able to see the metal part of the connector as
shown in the illustration.
• When connecting the USB cable to a USB port, make
sure you align the connector correctly with the port.
Connecting Directly to a PictBridge Compatible Printer
USB
USB cable
USB port
USB/AV port
Making sure that the 6 mark on the camera is aligned
with the 4 mark of the USB cable connector, connect
the cable to the camera.
Large connector
Small connector

Casio Exilim EX-Z29 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.5 \
Maximum image resolution	3648 x 2736 pixels
Digital zoom	4 x
Optical zoom	3 x
Combined zoom	12 x
Focal length range	6.2 - 18.6 mm
Lens structure (elements/groups)	6/5
Interface	USB 2.0
Digital SLR	No
Camera shutter speed	1/2 - 1/2000 s
Focal length (35mm film equivalent)	37.5 - 112.5 mm
Auto focusing (AF) modes	continuous auto focus, multi point auto focus, spot auto focus
Manual focusing range (wide)	∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	100
Light exposure modes	Auto
Motion JPEG frame rate	30 fps
Video formats supported	Avi, M-JPEG
Maximum video resolution	848 x 480 pixels
Audio system	Mono
Display diagonal	2.7 \
Display resolution (numeric)	479 pixels
I/O ports	A/V
USB version	2.0
White balance	auto, Cloudy, daylight, Fluorescent, manual, Tungsten
Camera playback	movie, single image, slide show
Self-timer delay	2 s
Playback zoom (max)	8 x
Product color	Black
Battery type	NP-60
Number of batteries supported	1
Flash modes	auto, Flash off, Red-eye reduction
Flash range (tele)	0.4 - 1.5 m
Flash range (wide)	0.15 - 2.8 m
Flash recharging time	6 s
Internal memory	17.8 MB
Compatible memory cards	sd
Camera shutter type	electronic, mechanical

Weight and Dimensions

Width	0 mm
Weight	125 g
