Casio Exilim EX-Z29 User Manual

77
Other Playback Functions (PLAY)
Procedure
[p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Rotation
1. Use [8] and [2] to select “Rotation” and then press [SET].
Each press of [SET] will rotate the displayed image 90 degrees left.
2. When the displayed image is at the orientation you want, press
[MENU].
NOTE
• Note that this procedure does not actually change the image data. It simply alters
how the image is displayed on the camera’s monitor screen.
• An image that has been protected or zoomed and movie screen cannot be rotated.
• The original (unrotated) version of the image will be displayed on the 12-image
screen.
Procedure
[p] (PLAY) * Snapshot Screen * [MENU] * PLAY Tab * Resize
You can reduce the size of a snapshot and save the result as a separate snapshot.
The original snapshot is also retained. You can select resize an image to one of three
image sizes: 7M, 4M, VGA.
• Resizing a 3:2 or 16:9 size snapshot will create an image with an aspect ratio of
4:3, with both sides cut off.
• The recording date of the resized version of the snapshot will be the same as the
recording date of the original snapshot.
Rotating an Image (Rotation)
Resizing a Snapshot (Resize)

Casio Exilim EX-Z29 Specifications

General

Megapixel	10.1 MP
Camera type	Compact camera
Sensor type	CCD
Image stabilizer	Yes
Image sensor size	1/2.5 \
Maximum image resolution	3648 x 2736 pixels
Digital zoom	4 x
Optical zoom	3 x
Combined zoom	12 x
Focal length range	6.2 - 18.6 mm
Lens structure (elements/groups)	6/5
Interface	USB 2.0
Digital SLR	No
Camera shutter speed	1/2 - 1/2000 s
Focal length (35mm film equivalent)	37.5 - 112.5 mm
Auto focusing (AF) modes	continuous auto focus, multi point auto focus, spot auto focus
Manual focusing range (wide)	∞ m
Light metering	Centre-weighted, Spot
ISO sensitivity	100
Light exposure modes	Auto
Motion JPEG frame rate	30 fps
Video formats supported	Avi, M-JPEG
Maximum video resolution	848 x 480 pixels
Audio system	Mono
Display diagonal	2.7 \
Display resolution (numeric)	479 pixels
I/O ports	A/V
USB version	2.0
White balance	auto, Cloudy, daylight, Fluorescent, manual, Tungsten
Camera playback	movie, single image, slide show
Self-timer delay	2 s
Playback zoom (max)	8 x
Product color	Black
Battery type	NP-60
Number of batteries supported	1
Flash modes	auto, Flash off, Red-eye reduction
Flash range (tele)	0.4 - 1.5 m
Flash range (wide)	0.15 - 2.8 m
Flash recharging time	6 s
Internal memory	17.8 MB
Compatible memory cards	sd
Camera shutter type	electronic, mechanical

Weight and Dimensions

Width	0 mm
Weight	125 g
