E-31
Handling microSD Cards
This Handheld Terminal supports microSD cards.
Use the procedure below to install a microSD card.
Installing
1. Open the microSD card slot cover ( ) and push the card all the way into the slot,
ensuring that the front of the microSD card is facing the front of the Handheld
Terminal ( ).
2. Close the microSD card slot cover.
Removing
1. Open the microSD card slot cover.
2. Pull the microSD card out and close the microSD card slot cover.
Important!
A microSD card must be inserted with the top and bottom properly aligned
and in the proper direction. Attempt in inserting it with an excessive force in
incorrect orientation can risk damage to the connectors and slot.
Never turn off the power or remove a microSD card from the slot while the card
is being accessed. Doing so can damage the microSD card or data in the card.
Do not drop the card or lose it.
•
•
•
