Casio LK-136 User Manual

EN-20
Reference
• Design and specifications are subject to change without notice.
Specifications
Model LK-135/LK-136
Keyboard 61 keys
Key Lighting Maximum number of keys simultaneously lit: 4
Maximum Polyphony 32 notes
Tones
Preset Tones 120
Effects Dance Music effects
Song Bank
Preset Songs 100
Easy Mode
Lesson Parts Left hand, right hand, both hands
Lesson Lite
Lesson Parts Left hand, right hand, both hands
Other Voice Fingering Guide, Note Guide, Performance Evaluation
Auto Accompaniment
Preset Rhythms 70 types
Dance Music Mode
Preset Patterns 50 types
Demo Function Looped play of the dance music demo (1 song) and built-in Song Bank (100 songs)
Other Functions
Transpose ±1 octave (–12 to 0 to +12 semitones)
Tuning A4 = 415.5 to 465.9Hz (Initial Default: 440.0Hz)
Musical Information System Tone, Auto Accompaniment, Song Bank numbers and names; staff notation; fingering guide;
tempo; measure number, beat; chord name, etc.
Jacks
PHONES/OUTPUT jack Stereo standard jack × 1
Output impedance: 140 Ω; Output voltage: 4.5 V (RMS) MAX
AC adaptor terminal 9.5 V DC
Power Requirements 2-Way Power
Batteries Six AA-size manganese batteries or AA-size alkaline batteries
Battery Life Approximately 6 hours (on alkaline batteries)
AC Adaptor AD-E95100L
Auto Power Off Approximately 30 minutes after last operation; Can be disabled.
Speakers 10cm × 2 (Output: 2.0W+2.0W)
Power Consumption 9.5V = 5.5W
Dimensions 94.6 (W) × 30.7 (D) × 9.2 (H) cm (37
1
/4 × 12
1
/8 × 3
5
/8 inch)
Weight (Excluding batteries) Approximately 3.5 kg (7.7 lbs)
LK135-ES-1A.indd 22 2016/08/22 14:43:43

Casio LK-136 Specifications

General

Tones quantity	120
RMS rated power	4 W
Number of speakers	2
Maximum polyphony (notes)	32
Music memory capacity (songs)	100
Keys quantity	61 keys
Pre-recorded drum patterns quantity	70
Product color	Black, White
Headphone outputs	1

Weight and Dimensions

Depth	307 mm
Width	946 mm
Height	92 mm
Length	3500 mm
