81
1. Remove the printer cover.
2. Remove the inner cover by grasping its top on
the left side and lifting up to the right.
3. Unroll about 10 centimeters of ribbon and
place the take-up spool on the left shaft.
4. Insert the ribbon into the ribbon feed slot
between the printer rollers. Loop the ribbon
around the outside guard brackets as in the
illustration.
5. Move the ribbon clip to the left. While holding
the clip open, place the feed spool on the right
shaft and take up any slack in the ribbon.
Important!
Use only the RAP-01 ribbon (purple). Other types of ink ribbons can damage the printer. Never try to
extend the life of an ink ribbon by replenishing the ink. Once an ink ribbon is in place, press the N or
n key to test for correct operation.
To replace the ink ribbon
Right spindle
Guides
Printer rollers
Spool
Guides
Feed slot
Left spindle
Spool
Troubleshooting
User Maintenance and Options
