— 40 —
7. DIAGNOSTIC PROGRAM
7-1. Starting the Program
(1) Check that the power is turned OFF.
(2) While holding down the INIT switch, turn on the power.
(3) Release the switch when the screen below appears.
* If the switch is released before this screen appears, either of the following modes is launched.
• Power-failure recovery reboot
• INIT boot-up
(4) Enter “99990000” and press [OK].
(5) When the program is launched, the software version information is printed out as shown below.
• BOOTER
• IOC
| IOC Ver : xxxx xxxxxx | IOC
| Boot Ver : xxxx xxxxxx | BOOTER
(6) After the version information is displayed and printed out, a
message appears prompting for an action to take as the next
step.
To proceed with the calibration settings, press the ON/OFF
key on the display. For detailed procedures, see “[15] LCD
CALIBRATION SETTING”. If you wish to skip the calibration
settings, press anywhere on the touch panel.
Init switch
Power switch
DALLAS
DRW 1CLOSE 2CLOSE
MAC ADRS XX-XX-XX-XX-XX-XX
TEMP 0 VOLTAGE 0 CHARGE-MODE 359M
DISP ON/OFF OFF CF NON
Ioc Ver : xxxxxx xxxx
Boot Ver : xxxxxx xxxx
TOUCH START
221
Enter the Calibration mode
==>> Push Disp on/off ke
y
Skip the Calibration mode
==>> Touch the pane
l
0000 00000221
PANEL SIZE 15"
Copyright(C)2008
CASIO COMPUTER CO.,LTD.
All rights reserved.
ROM VER. xxxxxx xxxx
C
1
0
4
7
2
5
8
3
6
9
CREATE
xxxx-xx-xx xx:xx
QT-6600 Version x.xx
APL VER. xxxxxx xxxx
OK
