Casio SE-G1 Manual

SE-G1/PCR-T273/SM-T274
– 28 –
6-1. EXPLODED VIEW
FINAL-ASSY
S-type M-type
EU &UK only
MAIN-UNIT
DL-2816
DL-2817
MAIN-UNIT
DL-1335
DL-1844
DL-1845
1
3
5
7
8
6
4
2
9
11
15
13
14
10
12
12
S2
S3
S1
S3
S4

Casio SE-G1 Specifications

General

Clerk lock	Yes
Memory type	Flash ROM
Number of users	8 user(s)
Keyboard number of keys	34
Supported paper width	58 mm
Backlight	No
Display digits	8 digits
Display number of lines	1 lines
Second display number of characters	8
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Power source	AC
Power consumption	100 mA

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3500 g
