Casio SE-G1 Manual

SE-G1/PCR-T273/SM-T274
– 30 –
6-2. PARTS LIST
1 SE-G1SB
2 SE-G1SD
3 SE-G1SG
4 SE-G1SA
5 SE-G1SK
6 SE-G1T
7 SE-G1MB
8 SE-G1MG
9 SE-G1MA
10 SE-G1MK
11 PCR-T273
12 SE-G1SC
13 SE-G1SB-WE
14 SE-G1SK-WE
15 SE-G1MB-WE
16 SM-T274
17 SE-G1SD-WE
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
FINAL-ASSY
1 10445446 COVER/PRINTER/BK RJE504003-001V01 1111111111 1 1 1 C
1 10448039 COVER/PRINTER/WE RJE504003-002V01 1 1 1 1 C
2 10445448 BOARD/RDP/BK RJE504001-001V01 111111111 1 1 1 1 C
2 10448040 BOARD/RDP/WE RJE504001-002V01 1 1 1 1 C
3 10445449 BOARD/DISPLAY RJE504012-001V01 111111111 1 1 C
3 10448287 BOARD/DISPLAY RJE504012-002V01 1 C
3 10448044 BOARD/DISPLAY RJE504012-003V01
1C
3 10448041 BOARD/DISPLAY RJE504012-004V01 1 1 1 1 C
4 10445436 COVER/BATTERY RJE504019-001V01 11111111111111111C
5 10349665 PULLY/WIND RJE501880-001V04 111111111 11111111C
6 10424040 SPOOL/PAPER RJE502545-001V02 111111111 11111111C
7 10325051 SUB ASSY/KEY SET RJE503007*003V01 11111111111111111C
8 10233584 SEPARATER/BILL RJE500103-001V02 1 1 1 1 C
9 10445447 COVER/PCB RJE504042-001V01 111111 1111 11C
10 10445450 COVER/CORD RJE504013-001V01 111111 1111 11C
11 10445437 COVER/TOP/BK RJE504044-001V01 1 1 1 1 C
11 10448042 COVER/TOP/WE RJE504044-002V01
1C
12 10230087 PLATE RJE500775-001V02 2 2 2 2 2 C
13 10445438 COVER/CORD RJE504014-001V01 1 1 1 1 1 C
14 10445439 COVER/PCB RJE504037-001V01 1 1 1 1 1 C
15 10331637 SUBASSY/TRAY RJE503185*001V01 1 1 1 1 C
15 10448043 SUBASSY/TRAY RJE503185*003V01
1C
S1 SCREW S-PAPT-3X16Z3 222222 2222 22
S2 SCREW S-BDPT-3X10Z3 333333 3333 33
S3 SCREW S-BDPT-3X8Z3 5 5 5 5 5
S4 SCREW S-BDST-3X8ZC 1 1 1 1 1
RN Item Code No. Parts Name Specification
Q'TY

Casio SE-G1 Specifications

General

Clerk lock	Yes
Memory type	Flash ROM
Number of users	8 user(s)
Keyboard number of keys	34
Supported paper width	58 mm
Backlight	No
Display digits	8 digits
Display number of lines	1 lines
Second display number of characters	8
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Power source	AC
Power consumption	100 mA

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3500 g
