CDA SV 150L Series User Manual

20
Oven Door
Depending on the model, the oven door is hinged either on the
left or the right.
Note: The oven door should only be removed by an authorised
service agent.
Removal of the oven door by a non-authorised person will
invalidate the guarantee.
Cleaning the Panes of Glass
The oven door is fitted with no. 2 panes:
- no. 1 outside;
- no. 1 inner.
To clean all panes on both sides it is necessary to remove the inner
pane as follows.
Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass since they scratch the surface, which
may result in shattering of the glass.
Removing the Inner Pane of Glass
When removing and replacing the inner glass, the door
should be held still by one person (fig. 8). A second person
should gently remove the glass (fig. 10).
To clean the inner pane of the oven door on both sides operate
as follows:
– Open the oven door.
– Remove the seal G by unhooking the no. 3 fixing hooks (fig. 9).
– Gently pull out the inner pane of glass (Fig. 10.). Forcible removal
of the door glass may lead to damage of the door hinges.
– Clean the glass with an appropriate cleaner. Dry thoroughly, and
place on a soft surface.
– Now you can also clean the inside of the outer glass.
G
Fig. 9
Fig. 10
Fig.8
