79033095 C Rev. 1-17
Introduction
MACHINE IDENTIFICATION
Machine Identification Information
Plate Locations
Machine identification number (PIN) is used to identify a
powered machine designed for an operator to ride.
Components such as engines, transmissions and major
attachments not designed for an operator to ride are
identified by serial numbers.
For quick reference, record identification numbers in
spaces provided below illustration.
FIG. 26: Machine PIN. Plate is located on left side of
frame rail.
Machine PIN: _________________________________
FIG. 27: Engine Serial Number. Plate is located on
engine.
Engine Serial Number: _________________________
FIG. 28: Transmission Serial Number. Plate is located on
left front side of transmission above hardball.
Transmission Serial Number: _____________________
FIG. 26
FIG. 27
FIG. 28
