Straight Door
Arm Section
Curved Door
Arm Section
Safety Labels
and
Literature
Header Bracket
UP
CEILING MOUNT ONLY
Belt Cap Retainer
2-Conductor Bell Wire
White & White/Red
Remote Control
Visor Clip
Door Bracket
SECURITY✚
®
3-Button Remote Control
The Protector System
®
(2) Safety Reversing Sensors
(1 Sending Eye and 1 Receiving Eye)
with 2-Conductor White & White/Black
Bell Wire attached
Safety Sensor
Bracket (2)
LCD Motion Detecting
Door Control Console
Motor Unit with Light Lenses
Battery
(Packed Separately)
LOCK
LIGHT
One-Piece
Rail
Styrofoam
Belt
Pulley Bracket
Belt
Trolley
Your garage door opener is packaged in two cartons which
contain the motor unit and all parts illustrated below. Accessories
will depend on the model purchased.
If anything is missing, carefully check the packing material. Parts
may be stuck in the foam. Hardware for installation is also listed
below.
Carton Inventory
Models 3850 (1)
3850-267 (2)
Optional EverCharge
®
Standby Power System
(battery)
Smart Control Panel
®
Remote Control
Visor Clip
SECURITY✚
®
Keyless Entry
Model 3850-267 (1) ONLY
INSTALLATION HARDWARE
Hex Bolt 5/16"-18x7/8" (4)
Hex Screw #8 x 3/8" (2)
Lag Screw 5/16"-9x1-5/8" (2)
Lag Screw 5/16"-18x1-7/8" (2)
Clevis Pin 5/16"x2-3/4" (1)
Clevis Pin 5/16"x1-1/4" (1)
Clevis Pin 5/16"x1" (1)
Nut 5/16"-18 (4)
Lock Washer 5/16" (4)
Screw 6ABx1-1/4" (2)
Self-Threading Screw 1/4"-14x5/8" (2)
Screw 6-32x1" (2)
Insulated Staples (10)
Ring Fastener (3)
Dry Wall Anchors (2)
Rope
Handle
Rail Grease
Carriage Bolt 1/4"-20x1/2" (2)
Wing Nut 1/4"-20 (2)
To Next Page
