Chevrolet Cruze Owner Manual - 2011
Vehicle Care 10-29
High‐Beam Headlamp/
Low‐Beam Headlamp and DRL
1. Open the hood. See Hood on
page 10‑4.
2. Remove the connector
retaining tab (A).
3. Disconnect the wiring harness
connector from the bulb (C)
by pressing the connector
release (B) and pulling
straight back.
4. Remove the bulb (C) from the
headlamp assembly by turning
counterclockwise and pulling
straight back.
5. Install the new bulb in the
headlamp assembly by turning
clockwise.
6. Install the wiring harness
connector to the bulb. Be sure
the connector release (B) locks
into place.
7. Install the connector
retaining tab (A).
Parking/Turn Signal Lamp
1. Open the hood. See Hood on
page 10‑4.
2. Remove the parking/turn signal
lamp bulb socket from the
headlamp assembly by turning
counterclockwise.
