Vehicle Care 10-33
8. Install the taillamp assembly and
tighten the two screws.
9. Close the two screw covers.
License Plate Lamp
To replace the license plate
lamp bulb:
1. Remove the two screws from the
license plate lamp assembly.
2. Turn and pull the license plate
lamp assembly down.
3. Turn the bulb socket
counterclockwise and pull the
bulb straight out of the socket.
4. Push the new bulb into the
socket.
5. Install the bulb socket by turning
clockwise into the license plate
lamp assembly.
6. Replace the license plate lamp
assembly by using the two
screws to secure.
Replacement Bulbs
Exterior Lamp
Bulb
Number
Back-Up Lamp 921K
Front and Rear
Sidemarker Lamp
194
Front Parking/Turn
Signal Lamp
7444NA
High Beam/Low
Beam and DRL
Headlamp
H13LL
Rear Turn
Signal Lamp
7443NA
Stop Lamp/Taillamp 3057K LCP
For replacement bulbs not listed
here, contact your dealer.
