Vehicle Care 10-27
Bulb Replacement
For the proper type of replacement
bulbs, see Replacement Bulbs on
page 10‑30.
For any bulb changing procedure
not listed in this section, contact
your dealer.
Headlamps, Front Turn
Signal, Sidemarker, and
Parking Lamps
1. Low Beam Headlamp
2. High Beam headlamp
3. Park/Turn Signal Lamp
4. Side Marker Lamp
To replace:
1. Turn the tire to reach the access
port cap located on front of
wheel well cover.
2. Remove screw (1) and turn
access port cap (2)
counterclockwise to remove.
3. If replacing low/high headlamp
bulb, remove the dust cover cap
from the back of the headlamp
housing by turning the cap
counterclockwise.
4. Turn the bulb socket
counterclockwise to remove from
lamp assembly.
5. Remove the bulb from the
socket or disconnect bulb
assembly from harness
connector.
6. Install new bulb.
7. Reinstall the lamp socket to
lamp assembly turning
clockwise.
8. Replace the dust cover cap on
headlamps.
9. Reinstall the wheel well cover
access port cap and secure by
installing screw.
