Diesel Engine Exhaust Brake
If your vehicle has a Isuzu 6H Diesel Engine, it may
have an exhaust brake, which is located in the exhaust
system.
If your vehicle has a 6.6L DURAMAX
®
6600 or
Caterpillar
®
Diesel Engine, it may have an exhaust
brake, which is controlled through the turbocharger.
The exhaust brake for both engines operates the same.
The exhaust brake switch
is located in the instrument
panel switchbank.
Push the bottom of the switch to turn the exhaust brake
on. When you push the top of the switch, the exhaust
brake will turn off.
There is an indicator light on the instrument panel
similar to the symbol on the switch, that comes on when
the exhaust brake is active. See Exhaust Brake
Indicator Light on page 3-40 for more information.
While using the exhaust brake, the proper gear range
selection is important. The exhaust brake is most
effective if the gear range selected is the lowest possible
range that does not allow the engine rpm to go more
than 200 rpm above rated (full load) rpm. If you have a
Caterpillar
®
Diesel Engine, do not exceed 2900 rpm.
If you have an Isuzu 6H Diesel engine, do not exceed
2550 rpm. If your vehicle has a DURAMAX
®
6600
Diesel Engine, do not exceed 3600 rpm.
If your vehicle has an Allison
®
1000/2200/2300/
2350/2500/2550 series automatic transmission and this
button is pressed, the transmission downshifts to a
factory default setting of third gear. To change
the default setting, or for more information on factory
default settings, contact your dealer/retailer for
assistance.
The accelerator and clutch pedals must be released in
order for the exhaust brake to engage. The exhaust
brake will automatically shut off when the antilock brake
system is active.
If your vehicle has a Caterpillar
®
Diesel Engine or a
DURAMAX
®
6600 Diesel Engine, the exhaust brake will
become active in cruise control when you exceed the
set speed by 3 to 5 mph.
2-26
