6-69
Fuse Usage
D/L Door Locks
STP Brake Light, Horn, Center
High
-Mounted Stop Lamp,
Cruise Control
FOG Not Used
DEF Rear Window Defogger, DRL,
Heater, Air Conditioning
S/H Not Used
TRN Turn Signal, Back
-Up Light,
Hazard Lights
WIP Windshield Wiper/Washer,
Rear Window Wiper/Washer
Fuses for the air bags are located next to the instrument
panel fuse block.
Engine Compartment Fuse Block
The engine compartment fuse block is located in the
engine compartment on the passenger’s side of the
vehicle and protects all electrical loads. See “Engine
Compartment Overview” in the Index for more
information on location.
For access to the main fuses, pull off the cover.
