2-10

Cisco Aironet 1240AG Series Access Point Hardware Installation Guide

OL-8371-05

Chapter 2 Installing the Access Point

Mounting Below a Suspended Ceiling

Note To comply with NEC code, a #10-24 grounding lug is provided on the mounting plate.

You should review Figure 2-4 before beginning the mounting process.

Figure 2-4 T-Rail Mounting Parts

1 Suspended ceiling T-rail 4 mounting plate

2 T-rail clips 5 Keps nut (contains an attached lock washer)

Plastic spacer (used with recessed ceiling

tiles)
