Cisco 3600 Series Installation Guide

5-48
Cisco 3600 Series Hardware Installation Guide
OL-2056-02
Chapter 5 Installing Memory in the Router
Installing and Formatting Compact Flash Memory Cards in Cisco 3631 Routers
Reinstalling the Cover
Caution Before reinstalling the cover on the router, make sure that all cables are securely tucked in and are
not in danger of being pinched or cut.
This section describes how to reinstall the router cover. You need a number 2 Phillips screwdriver or flat
blade screwdriver to perform this procedure:
Step 1 Place the chassis on a flat surface.
Step 2 Hold the cover at a 45-degree angle, and insert the tabs into the slots along the front (bezel) edge of the
chassis. (See Figure 35.)
Step 3 Center the cover over the chassis and lower it onto the chassis.
Figure 35 Replacing the Cover on a Cisco 3631
1 Insert tabs and slide cover 2 Close cover
62491
1
2
