Cisco Integrated Services Router Hardware Installation Guide
Appendix A Technical Specifications
Cisco 860, 880, 890 Series
ADSL2+ Port Connector Pinouts
Table A-22 lists the ADSL2+ connector pinouts.
V.92 Port Connector Pinouts
Table A-23 lists the V.92 connector pinouts.
G.SHDSL Port Connector Pinouts
Table A-24 lists the pinouts for the symmetrical high-speed DSL (G.SHDSL) WAN port for two-pair
products, including the following router model(s):
• C888
5Unused
6Unused
Table A-21 VDSL2 Connector Pinouts (RJ-11-to-RJ-45) (continued)
RJ-11 Pin Function
Table A-22 ADSL2+ Connector Pinouts (RJ-11)
RJ-11 Pin Function
1Unused
2Unused
3TIP
4RING
5Unused
6Unused
Table A-23 V.92 Connector Pinouts (RJ-11-to-RJ-45)
RJ-11 Pin Function
1Unused
2Unused
3TIP
4RING
5Unused
6Unused
