You can also configure the parameter in the configuration file (cfg.xml) by entering a string in the following
format:
<Unit_n_Key_m>fnc=sd;ext=9999@$PROXY;vid=n;nme=xxxx
Step 4 Click Submit All Changes.
Add Call Park on a Key Expansion Module Line Key
You can add call park to a Key Expansion Module line key to enable the user to temporarily store calls to the
same phone to which the Key Expansion Module is connected or to store calls to a different phone. The user
can also unpark the call from the line key.
Before you begin
Access the phone administration web page. See Access the Phone Web Interface.
Procedure
Step 1 Select Voice > Att Console.
Step 2 Select a Key Expansion Module line key on which to enable the call park.
Step 3 Enter a string in this format:
For a private line, enter
fnc=park;sub=$USER@$PROXY;nme=CallPark-Slot1
For a shared line, enter
fnc=prk;sub=$USER@$PROXY;nme=Call-Park1;orbit=<DN of primary line>
where:
• fnc= prk means function=call park
• sub= 999999 is the phone to which the call parks. Replace 999999 with a numbers.
• nme= XXXX is the name displayed on the phone for the call park line key. Replace XXXX with a name.
You can also configure the line-specific parameter in the configuration file (cfg.xml). Enter a string in the
following format:
<Unit_1_Key_1_ ua="na">fnc=prk;sub=$USER@$PROXY;nme=CallPark-Slot1</Unit_1_Key_1_>
Step 4 Click Submit All Changes.
Configure the LCD Brightness for a Key Expansion Module
You can configure the brightness of the LCD display on the key expansion module from the Attendant Console
tab.
You can also configure the parameters in the phone configuration file with XML(cfg.xml) code.
Cisco IP Phone Accessories
27
Cisco IP Phone Accessories
Add Call Park on a Key Expansion Module Line Key
