1. If you connect your headset to the phone with the Y-cable (RJ-9 connector and AUX connector) , make
sure that you enable Electronic HookSwitch Control in the Audio Volume area from Voice > User tab
on the phone administration web page.
2. When you use the Electronic Hookswitch (EHS):
• The EHS connects to the Cisco IP Phone 8811, 8841, and 8845 with the auxiliary port.
• The EHS connects to the Cisco IP Phone 8851, 8861, and 8865 with the auxiliary port, the USB port,
or with Bluetooth.
Note
Connect the Footstand
If your phone is placed on a table or desk, connect the footstand to the back of the phone.
Procedure
Step 1 Insert the connectors into the slots.
Step 2 Press the footstand until the connectors snap into place.
Step 3 Adjust the angle of the phone.
Secure the Phone with a Cable Lock
You can secure your phone with a laptop cable lock up to 20 mm wide.
Procedure
Step 1 Take the looped end of the cable lock and wrap it around the object to which you want to secure your phone.
Step 2 Pass the lock through the looped end of the cable.
Step 3 Unlock the cable lock.
Step 4 Press and hold the locking button to align the locking teeth.
Step 5 Insert the cable lock into the lock slot of your phone and release the locking button.
Step 6 Lock the cable lock.
Cisco IP Phone Accessories
3
Cisco IP Phone Accessories
Connect the Footstand
