Cisco Integrated Services Router Hardware Installation Guide
Chapter 1 Product Overview
Cisco 860, 880, 890 Series
Figure 1-53 shows the back panel of the Cisco C898EAG-LTE ISR.
Figure 1-53 Back Panel of the Cisco C898EAG-LTE ISR
Cisco C899G-LTE Integrated Service Router
Figure 1-54 shows the front panel of the Cisco C899G-LTE ISR.
Figure 1-54 Front Panel of the Cisco C899G-LTE ISR
372526
1 2 3 4 5 6 7 10 12118 9
131416 15
1 GE WAN interface 9 On/Off switch
2 SFP port 10 Reset button
3 4G port 11 Earth ground connection
4 USB port 12 Kensington security slot
5 SIM slots 13 4G antenna connector—M1/DIV
6 8-port Gigabit Ethernet switch 14 Active GPS antenna connector
7 Console/Auxiliary port 15 G.SHDSL over POTS
8 Power connector 16 4G antenna connector—M0/MAIN
372533
1 3
2
4
5
6
7
8
9
10
11
12
