A-2
Cisco Integrated Services Router Hardware Installation Guide
Appendix A Technical Specifications
Cisco 810 Series
Table A-1 Cisco 812 ISR Specifications
Description
C812G+7-K9
(3G only)
C812G-CIFI+7-E-K9
C812G-CIFI+7-N-K9
C812G-CIFI-V-A-K9
C812G-CIFI-S-A-K9
(3G + WiFi)
Physical Characteristics
Dimensions (H x W x D) 2.01 x 8.95 x 9.49 inches (51 x 227x 241 mm)
Weight 3.96 lbs (1.8 kg)
Maximum Power Consumption 11 W 18 W
Extended Shock-vibe No
IP41 (with DC adapter) No
Environmental Operating Ranges
Operating Temperature and
Altitude
–32 to 104 °F (0 to 40 °C)
Derate max operating temperature 1.5 °C per 1000 ft above 5000 ft
10,000 ft maximum except CCC
1
only up to 2000 meters.
Humidity Maximum 85% non-condensing RH
Ingress Protection Rating IP 20 per IEC 60529
Standard Safety Certifications
• UL 60950-1, 2nd edition
• CAN/CSA C22.2 No. 60950-1, 2nd edition
• EN 60950-1, 2nd edition
• CB to IEC 60950-1, 2nd edition with all group differences and national deviations
• AS/NZS 60950-1, Edition 1 (Australia and New Zealand)
EMC Emissions
• EN55022/CISPR22
• CFR 47 Part 15
• ICES003
• VCCI-V-3
• AS/NZS CISPR22
• CNS13438
• CISPR22
• CNS13438
• EN300-386
• EN61000-3-2
• EN61000-3-3
• EN61000-6-1
EMC Immunity
• EN55024/CISPR24 (EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5,
EN61000-4-6, EN61000-4-11)
• EN300-386
