Cisco Aironet 1000 Series Lightweight Access Point Hardware Installation Guide

OL-9403-04

APPENDIX

Priming Access Points Prior to Deployment

This section describes an optional procedure designed to prime or stage your access points in a

convenient location rather than after they are installed in possibly difficult to reach locations. This helps

limit potential installation problems to primarily Ethernet and power areas.

Figure E-1 illustrates a typical priming configuration for your access points.

Figure E-1 Typical Priming Configuration

58085

LWAPP

Default Chapter3
