Connect WAN and LAN Interfaces
This section describes how to connect WAN and LAN interface cables. Before you connect the interface
cables, refer to the following warning statements:
Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.
Statement 1036.
Warning
Never touch uninsulated telephone wires or terminals unless the telephone line has been disconnected at the
network interface. Statement 1037.
Warning
For connections outside the building where the equipment is installed, the following ports must be connected
through an approved network termination unit with integral circuit protection, LAN, PoE. Statement 1044.
Warning
Avoid using or servicing any equipment that has outdoor connections during an electrical storm. There may
be a risk of electric shock from lightning. Statement 1088.
Warning
Ports and Cabling
This section summarizes typical WAN and LAN connections for Cisco 1100 Series ISRs. The connections
summarized here are described in detail in the Cisco Modular Access Router Cable Specifications document
on cisco.com.
Table 3: WAN and LAN Connections
CableConnectionPort Type, Color
1
Port or Connection
Category 5 or higher
Ethernet
Ethernet hub or Ethernet
switch
RJ-45, yellowEthernet
Optical fiber as specified on
applicable data sheet
1000BASE-SX, -LX, -LH,
-ZX, -CWDM
LC, color according to
optical wavelength
Gigabit Ethernet SFP,
optical
Category 5, 5e, 6 UTP1000BASE-TRJ-45Gigabit Ethernet SFP,
copper
RJ-11 telephone cablePOTS or ISDN lineRJ-11xDSL
(VDSL2 / ADSL2/2+)
Install and Connect the Router
25
Install and Connect the Router
Connect WAN and LAN Interfaces

Cisco C1101-4P Specifications

General

DSL WAN	No
Ethernet WAN	Yes
Wi-Fi band	-
WLAN data transfer rate (max)	- Mbit/s
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Ethernet LAN (RJ-45) ports	4
Security algorithms	AES, WPA2
Product type	Tabletop router
Product color	Gray
Country of origin	China
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	30 W
Internal memory	4000 MB
Operating altitude	0 - 3000 m
Non-operating altitude	0 - 4570 m
Storage temperature (T-T)	0 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	333.502 mm
Package width	254 mm
Package height	177.8 mm
Package weight	3083.9 g
