Replace the Cover
The covers are an integral part of the safety design of the product. Do not operate the unit without the covers
installed. Statement 1077
Warning
To replace the cover, perform the these steps:
Step 1 Disconnect the power supply before you begin replacing the chassis cover.
Step 2 Confirm that the router is turned off and disconnected from the power supply (or power supplies) if there is redundant
power supply.
Step 3 Disconnect all port cables to ensure that no one works on the unit with attached cable in the event of lightning or surges.
Step 4 Place the chassis on a flat surface.
Step 5 Locate the cover hooks on the mating slots and slide the cover towards the bezel side.
Step 6 Secure seven screws on each side.
Locate Internal and External Slots for Modules
This section describes the locations of internal modules on the router motherboard.
Install an LTE Pluggable Module
To reduce the risk of electric shock, the chassis of this equipment needs to be connected to permanent earth
ground during normal use Statement 445
Warning
Blank faceplates and cover panels serve three important functions: they prevent exposure to hazardous voltages
and currents inside the chassis; they contain electromagnetic interference (EMI) that might disrupt other
equipment; and they direct the flow of cooling air through the chassis. Do not operate the system unless all
cards, faceplates, front covers, and rear covers are in place. Statement 1029.
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment. Statement
1030
Warning
Install a Micro-SIM Card onto a USB LTE Dongle
This section describes how to insert a micro-SIM card into a USB LTE dongle in a C1101-4P router.
Install and Upgrade Internal Modules and Field Replaceable Units
3
Install and Upgrade Internal Modules and Field Replaceable Units
Replace the Cover
