Cisco C9300L-24T-4X User Manual

Mounting the Switch in a Rack
Procedure
Step 1 Use the four supplied Phillips machine screws to attach the brackets to the rack.
Step 2 Use the black Phillips machine screw to attach the cable guide to the left or right bracket.
Figure 32: Front-Mounting Position
Number-12 or number-10 Phillips machine
screws
3Phillips machine screw, black1
--Cable guide2
Figure 33: Mid-Mounting Position
Cisco Catalyst 9300 Series Switches Hardware Installation Guide
58
Installing a Switch
Mounting the Switch in a Rack

Cisco C9300L-24T-4X Specifications

General

Model	C9300L-24T-4X
Category	Switch
Ports	24
Uplink Ports	4
Switching Capacity	128 Gbps
Stackable	Yes
DRAM	4 GB
Flash Memory	16 GB
Power Device	Internal power supply
Operating Temperature	32 to 104°F (0 to 40°C)
Management	CLI, SNMP, Web GUI
Input Voltage	100-240 VAC
Operating Humidity	10% to 85% non-condensing
