DescriptionTask
The various ports on the chassis must be connected
to the network. This process can involve only
attaching a network interface cable to the port or it
can include the installation of a transceiver of some
type in port and then attaching the network interface
cable to the transceiver.
Cabling the chassis and modules to the network
After completing the network cabling and making
sure that system ground is connected, the power
supplies can be turned on. The system powers up and
runs through a set of built-in diagnostics.
Powering up the chassis
Safety Warnings
Class 1 laser product. Statement 1008Warning
This unit is intended for installation in restricted access areas. A restricted access area can be accessed
only through the use of a special tool, lock and key, or other means of security. Statement 1017
Warning
This unit might have more than one power supply connection. All connections must be removed to
de-energize the unit. Statement 1028
Warning
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning
To prevent personal injury or damage to the chassis, never attempt to lift or tilt the chassis using the
handles on modules (such as power supplies, fans, or cards); these types of handles are not designed to
support the weight of the unit. Statement 1032
Warning
Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when
servicing. Statement 1034
Warning
This product requires short-circuit (overcurrent) protection, to be provided as part of the building installation.
Install only in accordance with national and local wiring regulations. Statement 1045
Warning
Catalyst 6880-X Switch Hardware Installation Guide
2 OL-30827-02
Installing the Switch
Safety Warnings
