Cisco Catalyst 6880-X Installation Guide

Installing the Power Supplies in the Switch Chassis
The chassis power supplies (AC or DC) might be shipped separately from the switch chassis. Remove the
power supply from its shipping packaging, and then install and connect it to the site power by referring to
Installing Power Supplies.
AC-input and DC-input power supplies can be mixed in a chassis.Note
Installing the Port Card in the Switch Chassis
The modular port card is optional and might be shipped separately from the switch chassis. Remove the port
card from its shipping packaging, and then install it, see the Installing a Modular Port Card section.
Connecting the Switch Console Port
This section describes how to connect to the supervisor engine console port from a terminal or modem. The
console port on the supervisor engine allows you to perform the following functions:
•
Configure the switch from the CLI.
•
Monitor network statistics and errors.
•
Configure SNMP agent parameters.
•
Download software updates to the switch, or distribute software images residing in flash memory to
attached devices.
The console port is located on the front panel of the chassis.
The accessory kit that shipped with your switch might contain the necessary cable and adapters (depending
on if you ordered them) to connect a terminal or modem to the console port. To connect a terminal to the
console port using the cable and adapters provided, follow these steps:
Procedure
Step 1
Connect to the port using the RJ-45-to-RJ-45 cable and RJ-45-to-DB-25 DTE adapter or RJ-45-to-DB-9 DTE
adapter (labeled "Terminal").
Step 2
Position the cable in the cable guide (if installed). Make sure there are no sharp bends in the cable.
Step 3
Check the terminal documentation to determine the baud rate. The baud rate of the terminal must match the
default baud rate (9600 baud) of the console port. Set up the terminal as follows:
•
9600 baud
•
8 data bits
•
No parity
•
1 stop bits
Catalyst 6880-X Switch Hardware Installation Guide
30 OL-30827-02
Installing the Switch
Installing the Power Supplies in the Switch Chassis
