Cisco Catalyst 9200CX Compact Series User Manual

CHAPTER 1
Product Overview
• Switch Models, on page 1
• Front Panel Components, on page 1
• Rear Panel, on page 6
• Network Configurations, on page 7
Switch Models
The Cisco Catalyst 9200CX Series switches have three compact (C9200CX) switch models. The following
tables describe all the available Cisco Catalyst 9200CX Series switches and the features supported.
Table 1: C9200CX Compact Switch Models and Descriptions
DescriptionSwitch Model
8x1G PoE+ ports; 2x1G and 2x10G SFP+ fixed uplink ports; powered
using 315W internal power supply unit; fanless.
C9200CX-8P-2X2G
12x1G PoE+ ports; 2x1G and 2x10G SFP+ fixed uplink ports;
powered using 315W internal power supply unit; fanless.
C9200CX-12P-2X2G
12x1G Ethernet ports; 3x1G Copper and 2x10G SFP+ uplink ports;
provides power either from one of the 3 copper uplink ports as Class
6 PD port or using an external auxiliary power adapter; fanless.
C9200CX-12T-2X2G
Front Panel Components
This section describes the front panel components of Cisco Catalyst 9200CX Series switches :
• 8 or 12 downlink ports of one of the following types:
• 10/100/1000
• 10/100/1000 PoE+
• 1G/10G Uplink ports
Cisco Catalyst 9200CX Compact Series Switches Hardware Installation Guide
1
