Mounting on a Wall or Ceiling Using Articulating Bracket
Figure 19: Exploded View of the Wall Mounting Articulating Bracket Hardware Assembly
Tightening ValuesQuantityMounting Bracket KitItem
#
Snug, hand tight4M4 X 10mm screw with washer1
—1AIR-AP-BRACKET-2
Not included in this kit.
2
—1Access point bracket plate3
—2M8 x40 Hex bolts4
—1Mounting arm5
—2M8 washer (external-tooth)6
