Cisco Expressway CE500 User Manual

Troubleshooting
Locating LEDs and components
Front view
Below is an illustration of the unit's front view and a list of the LEDs and components available.
Figure 3: Front view of the Cisco Expressway unit.
1 Power button/power status LED
2 Identification button/LED
3 System status LED
4 Fan status LED
5 Temperature status LED
6 Power supply status LED
7 Network link activity LED
8 Asset tag (serial number)
9 KVMconnector (for USB/VGA connection)
10 HDdrive activity/fault LED
Rear view
Below is an illustration of the unit's rear view and a list of the LEDs and components available.
Figure 4: Rear view of the Cisco Expressway unit.
1 Power supplies (one for CE500)
Cisco Expressway CE500 Appliance Installation Guide (X8.5) Page 12 of 16
Troubleshooting

Cisco Expressway CE500 Specifications

General

Brand	Cisco
Model	Expressway CE500
Category	Gateway
Language	English
