Cisco Expressway CE500 User Manual

Introduction
About this document
This document describes how to install a Cisco Expressway CE500 appliance into your video network. It
contains information on:
n Preparing the installation
n Installing the hardware
n Performing initial configuration
n Troubleshooting the installation
The Cisco Expressway appliance is based on the UCSC220 M3L. For more detailed information on installing
this appliance see Cisco UCS C220 Server Installation and Service Guide.
About the Cisco Expressway appliance
The Cisco Expressway appliance described in this document is a CE500, which is based on a UCSC220
M3L.
The appliance supports Cisco Expressway version X8.1.1 or later. Note that the CE500 model does not
support the scalability solution introduced in the X8.1 release.
The following table lists the components for the appliance:
Item Part Quantity
Chassis UCSC-C220-M3L 1
Processor UCS-CPU-E5-2643 (3.30 GHz / 4 Core - Hyper threaded) 1
RAM UCS-MR-1X082RY-A(8 GB) 2
Hard Disk UCS-HDD1TI2F212 (1TB NL SAS Disk LFF) 2
Onboard SAS Controller SASsupport provided by UCSC-RAID-ROM1 1
NIC N2XX-ABPCI01-M3 (Broadcom 5709 Dual Port 1 Gb) 1
PSU UCSC-PSU-650 W & Power cable 1
TPM UCSX-TPM1-001 (Trusted Platform Module) 1
Miscellaneous UCSC-BBLKD-L(HDD filler panel) 3
UCSC-HS-C220M3 (Heat Sink) 1
UCSC-RAIL1 (Rail Kit) 1
UCSC-PCIF-01H (Half height PCIe filler) 1
UCSC-PSU-BLKP (Power supply blanking panel/filler) 1
The only field replaceable component is the PSU.
Note: the hard disks must not be removed.
To initiate a Return MaterialAuthorization (RMA) go to http://www.cisco.com/web/ordering/cs_
info/or3/o32/Return_a_Product/WebReturns/product_Online_web_returns.html.
Cisco Expressway CE500 Appliance Installation Guide (X8.5) Page 3 of 16
