CHAPTER 5
Installation, Maintenance, and Upgrade
• Replace the SSD, on page 33
• Install the FIPS Opacity Shield in a Two-Post Rack, on page 34
Replace the SSD
The Firepower 1100 ships with an SSD installed. You can replace this SSD should it fail. Before replacing
the SSD, you must power off the chassis by pressing the power switch on the rear panel.
You will lose your configuration after you replace the existing SSD with a new SSD.
Caution
Follow these steps to replace an SSD in the chassis:
Step 1 Loosen the thumb screws on both sides of the SSD bay and pull the existing SSD out of the bay.
Step 2 Insert the new SSD into the bay and push it in until it is seated.
Cisco Firepower 1100 Series Hardware Installation Guide
33

Cisco Firepower 1120 Specifications

General

Processor cores	12
Processor family	Intel
Built-in processor	Yes
Firewall throughput	1500 Mbit/s
Wi-Fi	No
IPSec VPN throughput	1 Gbit/s
Maximum firewall connections	200000
Maximum firewall connections per second	75000
Supported network protocols	SMTP
Console port	RJ-45
Connectivity technology	Wired
Number of console ports	1
SFP module slots quantity	4
Ethernet LAN (RJ-45) ports	8
SSD capacity	200 GB
Storage media type	SSD
Form factor	1U
Input current	2 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	100 W
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Country of origin	Mexico
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	1409.7 mm
Package width	990.6 mm
Package height	457.2 mm
Package weight	5782.31 g

Weight and Dimensions

Depth	436.9 mm
Width	268.7 mm
Height	43.7 mm
