Figure 26: Remove and Install an SSD
Step 3 Tighten the thumb screws on both sides of the SSD bay.
Step 4 Check the SSD LED to make sure the SSD is seated properly and functioning. See Rear Panel LEDs, on page 9 for a
description of the SSD LED.
Install the FIPS Opacity Shield in a Two-Post Rack
Because the FIPS opacity shield covers the serial number on the chassis, the CO should copy the serial
number and store it in a secure place. The serial number is needed when you call Cisco TAC.
Note
Before you begin
This procedure should be performed only by the Crypto Officer (CO).
Caution
You need the following items to install the FIPS opacity shield:
• #1 Phillips screwdriver
• The following items from the FIPS kit (part number 800-105495-01):
Cisco Firepower 1100 Series Hardware Installation Guide
34
Installation, Maintenance, and Upgrade
Install the FIPS Opacity Shield in a Two-Post Rack

Cisco Firepower 1120 Specifications

General

Processor cores	12
Processor family	Intel
Built-in processor	Yes
Firewall throughput	1500 Mbit/s
Wi-Fi	No
IPSec VPN throughput	1 Gbit/s
Maximum firewall connections	200000
Maximum firewall connections per second	75000
Supported network protocols	SMTP
Console port	RJ-45
Connectivity technology	Wired
Number of console ports	1
SFP module slots quantity	4
Ethernet LAN (RJ-45) ports	8
SSD capacity	200 GB
Storage media type	SSD
Form factor	1U
Input current	2 A
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	100 W
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Country of origin	Mexico
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85176990
Package depth	1409.7 mm
Package width	990.6 mm
Package height	457.2 mm
Package weight	5782.31 g

Weight and Dimensions

Depth	436.9 mm
Width	268.7 mm
Height	43.7 mm
