8
Chapter 2: Cisco Connect
/
/
/
/
/
Device
1. Enter the Network name (SSID), Security Key, and
Security Type settings on your wireless device. To print
this information, click Print these settings.
Wireless Network Settings
2. After connecting your device, click Next.
3. Enter a name that will be used to identify the device
and click Finish.
Name Your Device
Parental Controls
For the computers you select, you can block or limit
Internet access to specific times. You can also block
specific websites.
Parental Controls Password
First-Time Access of Parental Controls
1. The first time you access parental controls, you will
be asked to create a parental controls password.
Complete the following:
Parental controls password Create a password that
protects access to parental controls.
Verify password Re-enter the password.
Secret question Create a secret question and answer
pair. If you forget the password, you can reset it by
correctly answering the secret question. Enter your
question.
Answer Enter the answer to your secret question.
Click OK to save your settings.
2. Select the computer that you want to set up parental
controls for. Then click OK.
Set Up Parental Controls For

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco M20 and is the answer not in the manual?

Cisco M20 Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3ab, IEEE 802.3u
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN interface typeGigabit Ethernet
Wi-Fi bandNo
Input current1.0 A
Rack mounting-
Bandwidth (first)2.4 GHz
Minimum system requirementsInternet Explorer 6, Safari 3, Firefox 2 \\r USB, \\r Windows XP SP3, Windows Vista SP1 or Windows 7\\r OS X Tiger 10.4.11, Leopard 10.5.8, or Snow Leopard 10.6.1
Ethernet LAN (RJ-45) ports4
Antennas quantity3
Antenna gain level (max)2.2 dBi
Security algorithmsWEP, WPA2
Product colorSilver, White
LED indicatorsPower
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 80 %
CertificationFCC, UL/cUL, ICES-003, RSS210, CE, Wi-Fi (IEEE 802.11b/g/n), WPA2TM, WMM®, Wi-Fi Protected SetupTM
Output voltage12 V
Weight and Dimensions IconWeight and Dimensions
Depth160 mm
Width202 mm
Height34 mm
Weight309 g
