The following figure shows the fan-side chassis features that you use when installing the chassis or replacing
its modules.
Figure 7: Fan-Side View of the Cisco Nexus 3132 Chassis
Console, Management,
and USB ports
3AC or DC power supply
(1 or 2)
1
Screw holes for mounting
brackets
4Fan modules (4)2
The following figure shows the port-side chassis features that you use when installing the chassis or replacing
its modules.
Figure 8: Port-Side View of the Cisco Nexus 3132 Chassis
Screw holes for mounting
brackets
4Selector switch, ID, and
Status LEDs
1
Grounding pad54 SFP+ ports (multiplexed
internally to the first
QSFP+ port)
2
32 QSFP+ ports3
Cisco Nexus 3000 Series Hardware Installation Guide
8
Overview
Overview of the Cisco Nexus 3132Q Switches

Cisco Nexus 3064 Specifications

General

Product Model	Nexus 3064
Category	Switch
Switching Capacity	1.28 Tbps
Form Factor	1 RU
MAC Address Table Size	32, 000 entries
Jumbo Frame Support	Yes
Jumbo Frame Size	9216 bytes
Operating System	Cisco NX-OS
Memory	4 GB
VLANs	4096
AC Input Voltage	100 to 240 VAC
AC Input Frequency	50 to 60 Hz
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Ports	48 x 10GE SFP+
Airflow	Port-side exhaust or port-side intake
Humidity	5% to 95% (non-condensing)
Power Supply	Dual hot-swappable power supplies
