Overview of the Cisco Nexus 31128PQ Switch
The Cisco Nexus 31128PQ (N3K-C31128PQ-10GE) is a 2 rack unit (RU) switch with 96 fixed 10-Gbps
enhanced small form-factor pluggable (SFP+) ports and 8 fixed 40-Gbps quad small form-factor pluggable
(QSFP+) ports, 1 management port, 1 console port, and 2 USB ports. This switch supports both port-side
exhaust and port-side intake airflow schemes. The switch requires one AC or DC power supply for operations,
but it can have a second power supply for redundancy.
The following figure shows the fan-side chassis features that you use when installing the chassis or replacing
its modules.
Figure 22: Fan-Side View of the Cisco Nexus 31128PQ Chassis
Fan modules (2)3Grounding pad1
Beacon (BCN) and Status
(STS) LEDs
4Power supply modules (2)2
The following figure shows the port-side chassis features that you use when installing the chassis or replacing
its modules.
Cisco Nexus 3000 Series Hardware Installation Guide
23
Overview
Overview of the Cisco Nexus 31128PQ Switch

Cisco Nexus 3064 Specifications

General

Product Model	Nexus 3064
Category	Switch
Switching Capacity	1.28 Tbps
Form Factor	1 RU
MAC Address Table Size	32, 000 entries
Jumbo Frame Support	Yes
Jumbo Frame Size	9216 bytes
Operating System	Cisco NX-OS
Memory	4 GB
VLANs	4096
AC Input Voltage	100 to 240 VAC
AC Input Frequency	50 to 60 Hz
Operating Temperature	32°F to 104°F (0°C to 40°C)
Storage Temperature	-40°F to 158°F (-40°C to 70°C)
Ports	48 x 10GE SFP+
Airflow	Port-side exhaust or port-side intake
Humidity	5% to 95% (non-condensing)
Power Supply	Dual hot-swappable power supplies
