Page #128 background image
Administering Your Cisco RV110W
Configuring Bonjour
Cisco RV110W Administration Guide 128
7
Configuring Bonjour
Bonjour is a service advertisement and discovery protocol. On the Cisco RV110W,
Bonjour only advertises the default services configured on the device when
Bonjour is enabled.
To enable Bonjour:
STEP 1 Choose Administration > Bonjour.
STEP 2 Check Enable to enable Bonjour.
STEP 3 To enable Bonjour for a VLAN listed in the Bonjour Interface Control Table, check
the corresponding Enable Bonjour box.
You can enable Bonjour on specific VLANs. Enabling Bonjour on a VLAN allows
devices present on the VLAN to discover Bonjour services available on the router
(such as http/https).
For example, if a VLAN is configured with an ID of 2, devices and hosts present on
VLAN 2 cannot discover Bonjour services running on the router unless Bonjour is
enabled for VLAN 2.
STEP 4 Click Save.
Configuring Date and Time Settings
You can configure your time zone, whether or not to adjust for Daylight Savings
Time, and with which Network Time Protocol (NTP) server to synchronize the date
and time. The router then gets its date and time information from the NTP server.
To configure NTP and time settings:
STEP 1 Choose Administration > Time Settings. The current time is displayed.

Table of Contents

Other manuals for Cisco RV110W

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Cisco RV110W and is the answer not in the manual?

Cisco RV110W Specifications

General IconGeneral
Ethernet LANYes
Cabling technology10/100Base-T(X)
Networking standardsIEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
VPN tunnels quantity10
Ethernet LAN data rates10, 100 Mbit/s
Ethernet LAN interface typeFast Ethernet
Wi-Fi standards802.11b, 802.11g, Wi-Fi 4 (802.11n)
Channels quantity13 channels
Top Wi-Fi standardWi-Fi 4 (802.11n)
Ethernet LAN (RJ-45) ports4
Input voltage12 V
Rack mountingNo
Number of users32 user(s)
Weight (imperial)0.61 lbs
Dimensions (WxDxH)150 x 150 x 30 mm
Operating temperature (T-T)32 - 104 °F
Compliance industry standardsIEEE 802.3, IEEE 802.3u
Supported data transfer rates10/100Mbps
Dimensions (W x D x H) (imperial)5.91 x 5.91 x 1.18 \
WLAN data transfer rates supported11, 54 Mbit/s
Supported network protocolsPPPoE, DHCP, PPTP, L2TP, IGMP, RSTP
Antennas quantity2
Antenna gain level (max)1.8 dBi
Firewall securityVPN
Security algorithmsWEP, WPA, WPA2, WPS
MAC address filtering-
Product colorBlack
CertificationFCC, CE, IC, cUL, Wi-Fi
Storage temperature (T-T)-20 - 70 °C
Storage relative humidity (H-H)5 - 90 %
Operating relative humidity (H-H)10 - 85 %
Weight and Dimensions IconWeight and Dimensions
Width150 mm
Height30 mm
Weight300 g
